deegee XFG IP68 Xenon Strobe Single Flash Beacon 12-70Vuc White Base 220mm x 256mm dia. Blue
This durable, large-format xenon strobe visual warning device features a polycarbonate base and dome lens, with lens options in Red, Amber, Green, Blue, or Clear. The unit includes onboard switches, allowing the installer to choose from four different flash rates. The standard 11 Joule models are compatible with 12Vuc, 24Vuc, 115Vac, or 230Vac power supplies (uc = ac or dc), and can be configured with either Double-flash (standard) or Single-flash signaling patterns. The device is supplied as a complete boxed beacon, including the base assembly and colored dome lens. Additionally, 5 Joule models are available for use with 10-100Vdc, 20-70Vac, and 100-130Vdc power supplies.
Additional information
| Nominal Supply Voltage (V) | 12-70 |
|---|---|
| Voltage Min (V) | 11 |
| Voltage Max (V) | 70 |
| Supply Type | UC |
| Lens Colour | Blue |
| Signal Colour | Blue |
| Base Colour | White |
| Height (mm) | 220 |
| Diameter (mm) | 256 |
| Size (mm) | 220 x 256 dia. |
| IP Rating | IP68 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 5 |
| Nominal Current Draw (A) | 0.35 |
| Light Source | Xenon |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85318070 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| Temperature Limits (C) | -20 to +55 |
| Base Material | Polycarbonate |
| Lens Material | Polycarbonate |
| GTIN | 5056711300439 |
| Luminous Intensity (cd) | 20 |
| Fuse (A) | 1 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Weight (kg) | 1.621 |
