deegee XFE IP65 Xenon Strobe Single Flash Beacon 12Vuc White Base 194mm x 146mm dia. Red
A high-dome xenon strobe beacon with an ABS base and polycarbonate lens offers a traditional design for visual warnings. Base options include White (standard), Black, or Red, while lenses are available in Red, Amber, Green, Blue, Yellow, or Clear. Four selectable flash rates are adjustable via on-board switches. Standard 11 Joule models are compatible with 12Vuc, 24Vuc, 115Vac, or 230Vac power supplies (uc = ac or dc), with options for Double-flash (default) or Single-flash patterns. The unit comes as a complete boxed beacon with the base and dome lens included. Additional voltage 5 Joule versions can be used with 10-100Vdc (20-70Vac) and 100-130Vdc supplies.
Additional information
| Weight (kg) | 0.628 |
|---|---|
| Nominal Supply Voltage (V) | 12 |
| Voltage Min (V) | 11 |
| Voltage Max (V) | 14 |
| Supply Type | UC |
| Lens Colour | Red |
| Signal Colour | Red |
| Base Colour | White |
| Height (mm) | 194 |
| Diameter (mm) | 146 |
| Size (mm) | 194 x 146 dia. |
| IP Rating | IP65 |
| GTIN | 5060995741970 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 11 |
| Nominal Current Draw (A) | 1.58 |
| Light Source | Xenon |
| Luminous Intensity (cd) | 65 |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85319000 |
| Fuse (A) | 2 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| CE Approved | Yes |
| Temperature Limits (C) | -20 to +55 |
| Base Material | ABS |
| Lens Material | Polycarbonate |
