deegee XFE IP65 Xenon Strobe Single Flash Beacon 12-70Vuc White Base 194mm x 146mm dia. Amber
The traditional xenon strobe beacon comes with a high dome, ABS base, and polycarbonate lens. Base colors include White (standard), Black, and Red, while lens options cover Red, Amber, Green, Blue, Yellow, or Clear. Four flash rates can be selected using on-board switches. Standard 11 Joule models are suitable for 12Vuc, 24Vuc, 115Vac, or 230Vac supplies (uc = ac or dc), with options for Double-flash (default) or Single-flash modes. Delivered as a complete beacon (Base assembly and Coloured dome lens). 5 Joule variants support 10-100Vdc (20-70Vac) and 100-130Vdc supplies.
Additional information
| Weight (kg) | 0.6055 |
|---|---|
| Nominal Supply Voltage (V) | 12-70 |
| Voltage Min (V) | 11 |
| Voltage Max (V) | 70 |
| Supply Type | UC |
| Lens Colour | Amber |
| Signal Colour | Amber |
| Base Colour | White |
| Height (mm) | 194 |
| Diameter (mm) | 146 |
| Size (mm) | 194 x 146 dia. |
| IP Rating | IP65 |
| GTIN | 5060995742090 |
| Mounting method | Surface mounting |
| User Selectable Functions | 4 Flash Rates |
| Flash Energy (J) | 5 |
| Nominal Current Draw (A) | 0.35 |
| Light Source | Xenon |
| Luminous Intensity (cd) | 65 |
| Order Unit | 1 |
| MOQ | 1 |
| Quantity Interval | 1 |
| Status | Active |
| Commodity Code | 85319000 |
| Fuse (A) | 1 |
| Fuse Type | TD |
| Fuse (Internal or External) | Internal |
| Country of origin | GB |
| RoHS | RoHS3 (EU DIRECTIVE 2015/863) compliant |
| RoHS Last Verified Date | 8th August 2024 |
| SVHC | No SVHC present |
| SVHC Candidate List Date | 27th June 2024 |
| Factory Set Flashing Frequency (FPM) | 60 |
| Number of Flash Functions | 4 |
| CE Approved | Yes |
| Temperature Limits (C) | -20 to +55 |
| Base Material | ABS |
| Lens Material | Polycarbonate |
